| Maximum speed | 90.0 Km/h |
| Longitudinal slope | 60.0 % |
| Cross slope | 40.0 % |
| Turning diameter between curbs | 18.3 m |
| Turning diameter overall exterior | 36.0 m |
| Rake angle | 32.0 ° |
| 31.0 ° | |
| Temperature range | -33…52 C |
| Permissible total weight | 13500.0 kg |
| Weight rigid | 18000.0 kg |
| Overall length | 7200.0 mm |
| Total width | 2500.0 mm |
| Total height loaded (unloaded) | 2690.0 mm |
| Ground clearance front (back) | 340.0 mm |
| Type | MAN D 0834 LFL – 4 stroke, 4 cylinders in line turbocharged, intercooler, cooled with water. |
| Displacement | 4580.0 l |
| Rated power | 151 kW (206HP) / 2400 rpm |
| Torque | 830 Nm / 1400 rpm |
| Level of pollution | EURO5 |
| Clutch | Type: F&S MFZ 395, single plate, dry; |
| Gearbox | Type: ZF 6S 800 TO, mechanical, with 6+1 gears. Reduction ratios: i = 6.58 – 0.78 |
| Distribution box | Type: G55 mechanical, permanent front coupled, 2 gears |
| Front axle | Type: PF 7, steering, driven, i = 6.07, |
| Rear axle | Type: PS 13, drive axle with lockable differential. i = 6.07 |
| Tires | Front single, rear Tires: 365/85.00R 20 Michelin profile on-off |
| Rim | Rims: 10.00 V20 |
| Options | Central Tyre Inflating System |
| Brake system | Integral pneumatic with 2 independent circuits front/rear, ABS |
